34″ Dia Tube Axial Fan – 5 Hp – 3 Phase – 20,000 CFM – Free Shipping
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Blade Diameter | 34 in |
| Item Thickness | 20 in |
| Axial Fan Bearing Type | Ball Bearing |
| Power Source | Corded Electric |
| Fan & Blower Type | Tube Axial |
| Color | Gray |
| Item Diameter | 34 in |
| Material | Steel |
| MPN | ABT340503 |
| Item Length | 50 in |
| Power Phase | 3 Phase |
| Brand | Cook Manufacturing |
| Type | Axial Fan |
| Manufacturer Warranty | 1 Year |
| Voltage | 208-230/460 V |
| Model | ABT34 |
| Amperage | 14.60 / 13.10 / 6.60 A |
| Features | Remote Grease Fittings |
| Country/Region Of Manufacture | United States |
| Mounting Location | Ceiling / Wall |
| Item Width | 38 in |
| Maximum Air Flow | 15,001 - 20,000 CFM |
New 34" Diameter Tube Axial Exhaust FanDirect From The Manufacturer - Cook Manufacturing- This Tube Axial Fan is designed to meet your business needs and conforms to OSHA & NFPA spray booth regulations. Specifications: Inside Diameter: 34"Height: 20"Housing: 18 Ga Steel HousingMotor Mount: 10 Ga Steel Motor MountDrive: Dual V BeltCFM: 20,000 Max CFM @ .25" Static PressureMotor: 5 Hp 3 Phase TEFC Motor - Mounted Outside Air StreamVoltage: 208-230/460 VAmperage: 14.60 / 13.10 / 6.60 AFan: WingFan 9 Blade Fan With Aluminum HubBearings: Dual Pillow Block Bearings - GreaseableHole Pattern: Sixteen 7/16" Diameter Holes on a 36-3/8" Bolt CircleApplications: Used For Many Common Applications - Cooling, Exhaust, Intake, Fume Extraction, Spray Booth (Wet Coat & Powder Coat) Warranty: All products manufactured by Cook Manufacturing are backed by a 1 Year Warranty. Lead Time: Exhaust fans are built to order. Typical manufacturing lead time is 3 -5 business days. Orders can also be expedited at no charge. Call or email to confirm if an order can be expedited. Shipping:Free shipping in the Contiguous United States to a commercial address with a loading dock or fork lift available. Additional fees may apply for limited access locations. This item can be also be shipped to and picked up from your local distribution center free of charge.
