DAYTON 5NKK5 Hat Channel Motorized Damper,100-240V 5NKK5
Specifications
| Brand | DAYTON |
| Type | Motorized Dampers |
| Voltage | 100 to 240 |
| Model | 5NKK5 |
| MPN | 5NKK5 |
| UPC | 190735347522 |
28.8 In.H-W 14.5 In.L Squ Mtrzd Contrl Dampr, For Nominal Duct Diameter 30 in, Damper Application Motorized, Number of Panels 1, Overall Height 29 3/4 in, Overall Length 14 1/2 in, Rough Opening Shape Square, For Duct Shape Square, Overall Width 29 3/4 in, Frame Material Thickness 14 ga, Blade Material Galvanized Steel, Maximum Air Pressure 4 in wg, Rough Opening Length 30 in, Rough Opening Width 30 in, Maximum Air Velocity 3500 fpm, Nameplate Voltage 100/240V AC This Dayton(R) power-open/spring-return, single-panel motorized channel-style damper regulates exhaust or supplies airflow in medium- and low-pressure commercial applications. Mill-finish extruded aluminum frame and louvers. TPV seals and stainless steel jambs minimize leakage. Channel frames for installations inside walls or duct.
