NBK Blower compatible with Dayton 1TDP3 (4C443) 75 CFM 3020 RPM 115V 60/50hz
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| MPN | Does Not Apply |
| Voltage | 115 V |
| Model | FN1TDP3 |
| Motor Type | PSC |
| Power Phase | 1 Phase |
| Brand | NBK |
| Power Frequency | 60 hz |
| Maximum Air Flow | Below 150 CFM |
| Type | Centrifugal |
Product Description Dynamically balanced, the NBK Blower, compatible with the Dayton model FN1TDP3 (4C443), mounts in any position and operates with minimal noise and vibration, to maintain CFM at higher static pressures. Motors have cast aluminum end shields for greater heat dissipation and protection, resulting in less downtime and longer service life. The NBK Blower is better quality and will last longer than the Dayton products. We no longer carry any Dayton products. Typical Application This fan is used on the Shaver Outdoor Wood Furnace & Taylor T-450. Also used for many other applications This blower is compatible to the following models: Dayton 1TDP3, Fasco 7021-4931,50748-D500, 4C443 Fasco 7021-10870, 7021-5713, 7021-2588, 9MRW2Performance Data CFM @ 0.000-In SP: 75 115 V, 60 Hz, Single Phase Max Ambient Temp: 104 Deg F Full Load Amps: 0.45 Motor RPM: 3020 Dimensions: Overall height 5 3/4'', overall width 6 1/4'', overall depth 6 7/16'' Features Noise and vibration are held to a minimum to maintain CFM at higher static pressures. Shaded Pole All-position mounting Min./max. operating temp. range: -20 Degree to 104 DegreeF Motor enclosure: Open Includes discharge mounting flange Wheel Type: Forward curve Blower Outlet Shape: Round
