Supco SHM350 Manual Reset Limit Control Thermostat – Open 350° – Close Manual
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | SUPCO |
| Model | SHM350 |
| MPN | SHM350 |
Supco SHM350 SHM-Series Snap-Action SPST Manual Reset Limit Control Thermostat The SHM-Series style temperature controls have a bi-metal disc that senses the temperature and quickly separates the contacts. This results in long life characteristics at loads up to 25 amps at 240 VAC. SHM-Series switches are single pole single throw 60T15 style (3/4”) with manual-reset. These switches are designed to open on temperature rise. The surface mounting configuration positions the disc against the mounting surface to sense the actual surface temperature. Each switch comes with an adapter flange plate. For air-stream installation, simply attach the SHM control with the bi-metal protruding through the mounting surface. For surface installation, insert the two spacers between the screw holes in the flange, and the heating surface. Install the original screws and tighten securely. Welded construction for integrity of current-carrying components. Limit - open on rise UL® recognized CSA approved SPECIFICATIONS RLA @ 120VAC / 240VAC: 25A Pilot Duty @ 120VAC / 240VAC: 125 VA LRA @ 240VAC: 30A LRA @ 120VAC: 60A FLA @ 240VAC: 5A FLA @ 120VAC: 10A Cut out temp (°F): 350° Cut in temp ( °F): Manual
